Modular audio video system with home cinema amplifier, decoder module for dts, dolby digital and prologic II and CD/DVD module.
Modular audio video system with home cinema amplifier, decoder module for dts, dolby digital and prologic II and CD/DVD module.
The modular construction of the Revox M51 enables you to create your own individual Revox World ranging from a standalone audio/video centre right up to a comprehensive Multiroom solution for the whole house. The M51 already contains the modules for DVD, decoder and amplifier. Further modules and functions up to the integration into the Revox Multiuser System can easily be added by plug and play.
You will find the fundamental idea of modularity has been consistently followed in the two different M51 output options. It is possible to equip your system with an analog 5 x 60 watt output or the more powerful 5 x 200 watt PWM output for particularly large rooms.
Features
Features
Technical details
dimensions
weight (kg): 20.5
length (mm): 460
height (mm): 136
width (mm): 400
AC supply voltage
230 V, 115 V
fuse rating
4 A, 8 A, slow-blow
power consumption
max. 500 Watt
operation
typ. 70 Watt
output power
5x 200 W music
frequency range
3 Hz - 60 kHz
surpression factor
200
harmonic distortion
0,003% at 50 Watt
headphone output
max. 1 V at 32 Ohm
